| Place of Origin: | China |
|---|---|
| Brand Name: | Whaleflo |
| Certification: | CE |
| Model Number: | HV-30B |
| Minimum Order Quantity: | 1set |
| Price: | 88-98USD/PC |
| Packaging Details: | 2pcs into a carton |
| Delivery Time: | 5-8 working days |
| Payment Terms: | Western Union，L/C, T/T， Paypal,, MoneyGram |
| Supply Ability: | 1000set per month |
| Theory: | Reciprocating Pump | Power: | Electric, On/off Switch |
|---|---|---|---|
| Pressure:: | Low Pressure | Volt: | 24V DC |
| Max Flow:: | 30-35LPM | Duty Cycle: | Working Intermittent |
| Body Material:: | Aluminium | Pump Design: | 5 Chamber Diahpragm |
| Diaphragm Material: | Viton | Speed: | 2800rpm |
| N.W/G.W: | 5/5.5KG | Amps: | 7.5A |
| PSI: | 30-35 |
| Voltage | 12v,24v,DC,115V,220V,230V AC |
| Self-Priming | More than 3 meters |
| Port Size | Hose tail connection 3/4'' |
| Pressure Max. | 40PSI(2.8Bar) |
| Diaphragm/check value Material | Viton |
| Body Material (DC): | Polypropylene |
| Body Material(AC): | Aluminium |
| Liquid of applications: | specially for Adblue liquid,fresh water, weak acid&basicity liquid, |
| Model | Volts | Open Flow(LPM) | Pressure(Psi/bar) | Amps(A) | Power(W) | Speed(rpm) | N.W / G.W(kgs) |
| HV-30A | 12 Vdc | 30-35 | 40 psi(2.8 bar ) | 15 | 180 | 2800 | 5/5.5 |
| HV-30B | 24 Vdc | 30-35 | 40 psi (2.8 bar) | 7.5 | 180 | 2800 | 5/5.5 |
