| Place of Origin: | China |
|---|---|
| Brand Name: | Whaleflo |
| Certification: | Rohs/CE/ISO9001 |
| Model Number: | FLO-2402A |
| Minimum Order Quantity: | 1 piece |
| Price: | USD8.99-9.99USD/piece |
| Packaging Details: | 1pc/box,10pcs/ctn |
| Delivery Time: | 5-8 work days after confirmed |
| Payment Terms: | L/C, T/T, Western Union, Western Union,Paypal |
| Supply Ability: | 10000 per month |
| Theory: | Electromagnetic Pump | Structure: | Diaphragm Pump |
|---|---|---|---|
| Typical Application: | Marine/RV/Camping/Water Treatment/Beverage/Food Service/Agriculture Irrigation/General Industrial/Automotive | Pump Design: | 2 Chamber Diaphragm |
| Port Size: | 3/8"BSPT Female Thread | Voltage: | 12V DC |
| Check Valve: | EPDM/VITON | Liquid Temp: | (60℃）Maximum |
| Self-Priming: | 4feet/1.2M Suction Lift | Max Flow LPM: | 4LPM(1.0gpm) |
| Max Pressure: | 80Psi(2.4bar) | Amps: | 1.3 |
| N.W/G.W: | 0.68/0.72KGS |
Ultra compact 12V caravan water pump delivers 4.3 L/min at 80 PSI and is designed to pump water to a single outlet in your caravan or for a single sink or tap in a camping situation.
A versatile water pump with duplex diaphragm design, this 12V caravan style pump is easy to operate, light, portable and self priming. These water pumps automatically turn themselves on and off when you turn the tap on and off, and are for intermittent use.
FEATURES & BENEFITS| Whaleflo Micro water pump | |
| pump style | 2 chamber diaphragm |
| motor | Permanent |
| inlet/outlet port | 3/8"(10mm)hose barb |
| max pressure | 80psi |
| diaphragm materials | viton or epdm |
| Priming Capabilities | 4 feet (1.2 m) suction lift |
TECHNICAL DETAILS| Model | Volt(V) | Flow Rate(LPM/GPM) | Demend Pressure(PSI/Bar) | Amp Draw(A) |
| FLO-2201 | 12 | 2.0(0.52) | 55(3.79) | 1.8 |
| FLO-2202 | 12 | 3.8(1.0) | 35(2.41) | 3.0 |
| FLO-2202-1 | 12 | 4.3(1.13) | 35(2.41) | 3.5 |
| FLO-2203 | 12 | 2.6(0.68) | 70(4.83) | 2.1 |
| FLO-2203-1 | 12 | 3.1(0.82) | 70(7.83) | 2.2 |
| FLO-2202A | 12 | 4.0(1.05) | 80(5.52) | 2.6 |
| FLO-2401 | 24 | 2.0(0.52) | 55(3.79) | 0.9 |
| FLO-2402 | 24 | 3.8(1.0) | 35(2.41) | 1.5 |
| FLO-2403 | 24 | 2.6(0.62) | 70(4.83) | 1.0 |
| FLO-2402A | 24 | 4.0(1.05) | 80(5.52) | 1.3 |
|
Whaleflo 2 Chamber Diaphragm DC Pump FLO Series designed for a wide range of applications including liquid transfer, spraying, circulation, filtration and dispensing.
It built-in pressure switch which automatically starts and stops the pump when faucet is opened and closed.
|
||||
| Dimension/pc | 18.5*11*6.5cm |
| Net Weight/pc | 0.64kg |
| Gross Weight/pc | 0.72kg |
| Carton Dimension(50pcs) | 56.5*38.5*36.5cm |
