Home ProductsSolar Storage Battery48v 86Ah 4.4kwh 120Ah 6.1kwh LifePO4 Power Box Lithium Battery Manufacturer

48v 86Ah 4.4kwh 120Ah 6.1kwh LifePO4 Power Box Lithium Battery Manufacturer

48v 86Ah 4.4kwh 120Ah 6.1kwh LifePO4 Power Box Lithium Battery Manufacturer
48v 86Ah 4.4kwh 120Ah 6.1kwh LifePO4 Power Box Lithium Battery Manufacturer 48v 86Ah 4.4kwh 120Ah 6.1kwh LifePO4 Power Box Lithium Battery Manufacturer
Basic Information
Place of Origin: China
Brand Name: Whaleflo
Certification: CE/UN38.3/MSDS/EMC/RoHS
Model Number: POWERBOX-4400
Minimum Order Quantity: 10pcs
Price: neogatiable
Packaging Details: carton box/wooden box
Delivery Time: 2-4weeks
Payment Terms: T/T
Supply Ability: 1200pcs/month
Contact Now
Battery Cell Material: Lithium LiFePO4 IP Protection: IP20
Weight: 48kg Operation Temp: 0-45℃
Storage Temperature: -20℃-45℃ Cycle Life: ≥5000
Operating LIfe: 10years Communication Port: RS232/RS485/CAN
Communication Mode: Wifi/bluetooth Operation Atitude: ＜3000M
Warantty: 5years Installation: Ground Mounted/Wall Hanging
Nominal Energy Capacity: 4400kWh Nominal Voltage: 51.2V
Operating Voltage Range: 40-58.4 Continuous Charge Current: 43A
Continuous DisCharge Current: 60A Depth Of Discharge: 80%

48v 86Ah 4.4kwh 120Ah 6.1kwh LifePO4 Power Box Lithium Battery Supplier

Home Battery Storage Description:

Battery Type: Lithium Ion, LiFePO4
Battery Capacity:4.4KWH/6.1KWH
Voltage:48V/51.2V
Application:Solar Energy Storage System
Cycle life:5000 Times
Warranty:5YEARS

Shipping: Sea

4.4kwh 6.1kwh Battery Features



Communication Port:RS232 / RS485 / CAN
Communication Mode:WIFI/BLUETOOTH
5Years warranty,≥5000 Cycles
Parallel 16 units





WALL MOUNTED BATTERY TECHNICAL PARAMETER

Ground-mountable

5 years warranty

≥5000 Cycles

Parallel 16 units





Datasheet
POWERBOX-4400
POWERBOX-6100
Dimensions (H x W x D)
(mm / ")
146.2 * 434.5 * 450.5mm 5.756 * 17.1 *
17.736’’

184.2 * 434.5 * 450.5mm 7.252 * 17.1 *
17.736’’


Weight (Kgs)
 46.2 58.8
Operating Temperature
0 to 45℃ / 0 to 113℉
0 to 45℃ / 0 to 113℉
IP Protection IP20 IP20
Storage Temperature
-20 to 45℃ / -68 to 113℉
-20 to 45℃ / -68 to 113℉
Cycle Life (80% DoD @25℃)
≥5000
≥5000
Operating Life (Years)
10
10
Communication Port
RS232 / RS485 / CAN
RS232 / RS485 / CAN
Communication Mode
WIFI/BLUETOOTH
WIFI/BLUETOOTH
Operating Altitude (m)
＜3000
＜3000
Humidity Conditions (%)
5% to 95%
5% to 95%
Warranty (Years)
5 Years
5 Years
Installation
Ground Mounted
Ground Mounted
Specifification

Nominal Energy Capacity
(Wh)
4400
6100
Nominal Voltage (V)
 51.2 51.2
Operating Voltage Range
 49-56.8 49-56.8
Continuous Charging
Current (A)
 43 60
Continuous Discharging
Current (A)
 60 80
Depth Of Discharge (%)
 80 80
Battery Cell Material
Lithium (LiFePO4)
Lithium (LiFePO4)
Certifification
UN38.3 CE-EMC CE-LVD MSD ROHS
UN38.3 CE-EMC CE-LVD MSD ROHS



48v 86Ah 4.4kwh 120Ah 6.1kwh LifePO4 Power Box Lithium Battery Manufacturer 0

Application



Smart
Intelligently select and use energy from grid / solar / battery storage



Efficient

Real-time tracking of power generation consumption to optimize energy utilization



Reliable
Multiple protections by BMS to ensure system safe and stable





48v 86Ah 4.4kwh 120Ah 6.1kwh LifePO4 Power Box Lithium Battery Manufacturer 1
