Name: Whaleflo 24V DC mini deep well solar powered water pump for irrigation
Brand: Xiamen Whaleflo Industry and Trade Co.,Ltd.
SKU: WEL2460-30
Price: 91.98 USD
Availability: InStock

Whaleflo 24V DC mini deep well solar powered water pump for irrigation

Basic Information

Place of Origin:	China
Brand Name:	Whaleflo
Certification:	CE,ISO9001
Model Number:	WEL2460-30

Minimum Order Quantity:	1 piece
Price:	USD89.98-95/pc
Packaging Details:	Strong Export carton
Delivery Time:	7-15days after confirmed
Payment Terms:	L/C,T/T,Western Union,Paypal
Supply Ability:	100000 Piece/Pieces per Month

Contact Now

Application:

Home

Output Voltage (V):

24V

Work Time (h):

24Hours

Certificate:

ISO9001,CE

Warranty:

1 Year

Material:

Stainless Steel

Maximum Lift:

100m

Maximum Submerion:

100 Feet Maximum (30m)

Outlet Port:

1/2''

Motor:

Permanent Magnet, Thermally Protected

Amps:

5.0A

Flow:

8L/12L/20L

Whaleflo 24V dc solar water pump dc solar submersible pump with lift rate 100m and flow rate 12L/M for irrigation

Application

Designed to use with solar panels and 24V battery systems for livestock watering, irrigation, ponds, remote homes and cabins.

Whaleflo 24V DC mini deep well solar powered water pump for irrigation 0

The submersible pump is the solution to your remote water pumping needs. This pump is rugged, durable and built to last.

Its unique water-tight power connector stops water wicking and prevents potential condensation problems.

Great for livestock watering, irrigation, pond areation, remote homes and cabins - any place where potable water is needed.

Solar submersible pumps can solve your long-distance water trouble, which is a sturdy and durablewater pump, it can at a maximum depth of 70 meters for your continued to provide 3 to 6 liters / minute of water flow, generally used for outdoor long-range water operating.

* Solar-powered submersible pump suitable for wells with a 4 inch diameter or larger.

*Designed to be strong and yet lightweight.

*Wide-range of parts and kits for ease of rebuilding and repair.

Features&Benefits

Pump:

*Strong Construction, yet lightweight.

*Dry Running capability without pump damage.

*Internal Bypass Feature for pump protection.

*Long-life,24VDC Operation.

*Easily repaired in the field.

*State of the art solid diaphragm.

Power Connector:

*Unique water-tight gland connector.

* Stops water wicking and prevents potential condensation.

*Quick Discounnect-No splicing necessary.

*Accepts a variety of jacketable cables.

Whaleflo 24V DC mini deep well solar powered water pump for irrigation 3

Pump Design	Positive Displacement 3 Chamber Diaphragm Pump
Motor	Permanent Magnet, Thermally Protected
Voltage	24V / 12V DC Nominal
Voltage	24V / 12V DC Nominal
Internal Bypass	105-110PSI Max.(7.2-7.5 BARS)
Maximum Lift	100m Maximum
Maximum Submerion	100Feet Maximum (30m)
Outlet Port	1/2''(12.7mm) Barbed Fitting for 1/2'' (12.7mm) I.D.Tubing
Inlet	50 Mesh Stainless Steel screen
Material	High Strength Engineered Plastics, Stainless Steel Fasteners

Model	Volt	Flow rate	lift(m)	Amps	Body cover
WEL2440-30	24V	6.0LPM(360LPH)	70	4.0A	Plastic body
WEL1240-30	12V	6.0LPM(360LPH)	70	8.0A	Plastic body
WEL2460-30	24V	12.0LPM(720LPH)	100	5.0A	Stainless steel body
WEL1260-30	12V	12.0LPM(720LPH)	100	10.0A	Stainless steel body

product show

Whaleflo 24V DC mini deep well solar powered water pump for irrigation 12

A	Life Plate
B	Cable Plug Kit
C	Valve Kit
D	Lower Housing Assembly Kit
E	Motor Kit
F	Canister Kit
G	Filter Screen Kit
H	O-ring Kit

Whaleflo 24V DC mini deep well solar powered water pump for irrigation 14

Whaleflo 24V DC mini deep well solar powered water pump for irrigation 16

Whaleflo 24V DC mini deep well solar powered water pump for irrigation 17

Whaleflo 24V DC mini deep well solar powered water pump for irrigation 18

Whaleflo 24V DC mini deep well solar powered water pump for irrigation 19

Whaleflo 24V DC mini deep well solar powered water pump for irrigation 20

Whaleflo 24V DC mini deep well solar powered water pump for irrigation 21

Application:

Whaleflo 24V DC mini deep well solar powered water pump for irrigation 23

Applications

Livestock drinking water, irrigation, pond water change, remote home and small log cabin water supply

Sample order is welcome testing.

Xiamen Whaleflo Industry and Trade Co.,Ltd.

Room 313,No.185-3 Qianqiuye Business Centre,Jintai Road,Huli district,Xiamen,China.

86--0592-5756220
