| Place of Origin: | China |
|---|---|
| Brand Name: | Whaleflo |
| Certification: | CE,RoHs |
| Model Number: | WLEBP-G2000-24 |
| Minimum Order Quantity: | 20 |
| Price: | USD15-18/pc |
| Packaging Details: | 1pcs per box, 20pcs in a carton |
| Delivery Time: | 7-15 WORK DAYS |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 Piece/Pieces per Month |
| Volt: | 24V DC | Flow Rate: | 2000GPH |
|---|---|---|---|
| Head: | 6M | Volt/Current: | 24V/5A |
| Wire: | 100cm | Outlet Dia: | 29mm |
| Usage: | Yacht,marine, River Or Other Solar Energy |
| Quantity(Piece) | 1 - 100 | 101 - 1000 | >1000 |
| Est. Time(day) | 10 | 18 | To be negotiated |
Votage: 12V DC/24V DC
Amps: 8.0A/5.5A
Flow Rate: 2000 GPH
Head: 6M
Outlet ports: 29mm/1-1/8"
Temperature limits: 110°F( 43°C)
Wire lead: 1m
Duty Cycle: intermittent
APPLICATIONS
Typically used in boat hulls / bilges
Bait tanks
Ponds, pools, spas
Other applications where you have to remove water from
Note: These pumps are designed for intermittent use only, NOT designed for continuous use
Note: Bilge and aerator pumps must be lower than the source of water for priming
FEATURE
Pump and switch are stand alone products
Compact , efficient, long life motors
New mercury free float switches
Anti-Airlock protection
Exclusive moisture tight seals
Completely submersible
Marine grade bolaked wiring
Silent and vibrationless operation
Non-automatic bilge pumps offer traditional operation activated by a float or panel switch. Removal of the motor cartridge allows for easy cleaning of the strainer and impeller in the event that the pump becomes clogged with debris. Electric Submersible Pumps are by far the most popular type of electric Bilge Pumps, submersibles give very high outputs, and cost effective, have low amp draw and are easy to install. They are designed to fit in the lowest part of the bilge and only require discharge pipe work and electricity supply. Also can be used in other applications like transfer river water, work together with solar panel or battery.
STANDARD PUMP CONFIGURATIONS
| Model | Volt | FLow | Current | Head | Wire | Outlet Dia | N.W/G.W |
| WELBP-G-2000-12 | 12 | 2000GPH | 10.0A | 6m | 1.0m | 29 mm/1-1/8″ | 1.13/1.26 kg |
| WELBP-G-2000-24 | 24 | 2000GPH | 5.0A | 6m | 1.0m | 29 mm/1-1/8″ | 1.13/1.26 kg |
| Key | Description |
| 1 | Wire Buckle |
| 2 | Pump Housing |
| 3 | Motor |
| 4 | Seal Base |
| 5 | Seal |
| Key | Description |
| 6 | Motor Bracket |
| 7 | Impeller |
| 8 | Pump Cover |
| 9 | Tapping Screw |
| 10 | Strainer |
| Shipping Information | |
| Unit Weight: | 1.31kgs |
| Unit Size: | 13.8*14*18.2 cm |
| Master Carton Qty: | 20pcs |
| Master Carton Size: | 71*29*39cm |
| Master Carton Weight: | 25.3kgs |
