| Place of Origin: | China |
|---|---|
| Brand Name: | Growatt |
| Certification: | CE(IEC/EN62109-1,-2),ROHS2.0 |
| Model Number: | SPF 5000ES |
| Minimum Order Quantity: | 5pcs |
| Price: | 50$ |
| Packaging Details: | carton box |
| Delivery Time: | 7-15 days after confirmed |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 10000pcs/month |
| Application: | Perfect For Off-grid , Backup Power And Self-consumption Applications. | Battery Voltage: | 48v Dc |
|---|---|---|---|
| Battery Type: | Lithium/Lead-acid | INVERTER OUTPUT: | 5000VA/ 5000W |
| Parallel Capability: | Yes, 6 Units Maximum | AC Voltage Regulation: | 230VAC ± 5%@50/60Hz |
| Surge Power: | 10000VA | Efficiency (Peak): | 93% |
| Waveform: | Pure Sine Wave | Transfer Time: | 10ms Typical, 20ms Max |
| Max. Recommended PV Power: | 6000W | MPPT Range @ Operating Voltage: | 120VDC ~ 430VDC |
| Maximum PV Array Open Circuit Voltage: | 450v DC | Number Of Independent MPP Trackers/ Strings Per MPP Tracker: | 1/1 |
| Maximum Solar Charge Current: | 100A | Efficiency Peak: | 93% |
| AC CHARGE CURRENT: | 80A | AC Input Voltage: | 230VAC |
| Selectable Voltage Range: | 170-280 VAC (For Personal Computers) ; 90-280VAC (For Home Appliances) | Frequency Range: | 50Hz/60Hz (Auto Sensing) |
| Protection Degree: | IP20 | Dimension (W/H/D): | 330/485/135mm |
| Net Weight (kgs): | 12kg | OPERATING ENVIRONMENT: | Humidity 5% To 95% Relative Humidity(Non-condensing) |
| Altitude: | <2000m | Operating Temperature: | 0°C - 55°C |
| Storage Temperature: | -15°C - 60°C |
